Single- or multi-unit automated circulation of WB ink

Automated WB ink circulation with great performance.

Based on 40 years of proven performance TRESU has further refined the new modular platform for ink circulators and InkFlex is the latest edition of the new generation of circulators.

With the highly automated TRESU InkFlex controlling your WB printing application, you can now save resources and exploit the full potential of your printing.

With TRESU's new HMI with intuitive graphical user interface operators’ start up times are optimized with fast and easy guidance to basic start up and operation commands and the ability to access a range of automated operation modes as well.

TRESU InkFlex main features:

• Fast and easy operation with intuitive user-friendly HMI interfacE

• Two air operated double diaphragm pumps for wide range of WB printing applications

• OPTIONAL Digital flowmeter for accurate flow- and temperature measurements

• Automated wash and OPTIONAL detergents operation for improved uptime

• Reduced micro-foaming with OPTIONAL TRESU pressure control technology

• Buy modules you need now – no more, no less: Modular platform with swift activation of already built-in features if future printing needs change

• Indicative maintenance information based on number of pump strokes

• Strong construction with TRESU flexo know-how and quality parts inside

• Optional Industry 4.0 connectivity integrating with any OEM technology

DATASHEET        CIRCULATOR ANIMATION  TECHNOLOGY ANIMATION                                                                                                                                                                                                                              TECHNICAL SPECIFICATIONS APPLICATIONS Fluids - water-based   Open/closed chamber system OPERATIONAL RANGE Max flow up to 20 l/min Max viscosity 24 sec (DIN4 cup) 70 [cP] POWER Max power consumption 150 W AIR Air consumption: max fluid flow 150l/min Air consumption. standard fluid flow 130 L/min PRESSURE Pressure control range - 0 - 2,500 mBar WASTE CONSUMPTION Ink Waste up to 10% of total volume Cleaning time quick wash - 5min Water waste regular wash:  3x total vol. Cleaning time regular wash - 10 min Water waste intensive wash - 4x total volume Cleaning time intensive wash - 15 min  CLOSED CHAMBER SYSTEM  Standard operational pressure 15 [mBar] - 30 [mBar] Max chamber pressure 500 [mBar] OPTIONS Remote access, External bus interface, chamber contrl, OEM integration and design, Detergent pump, auto refill, pressure control, agitator/stirrer, Ink level surveillance by scale, Tray level control, Chamber  position surveillance, light tower
